Electrode Caps 1
| Code | Material/Coating | Rod Diameter | Cross Section |
|---|---|---|---|
| CEB.101.01 | B-D1-N-S | ø16 - 22 mm | 16-70 mm² |
| CEB.101.03 | B-D1-N-S | ø18 - 22 mm | 95-240 mm² |
| Code Explanation | ||
|---|---|---|
|
Main Material A = Aluminum B = Copper D = Iron and Steel F = Bronze G = Cast Iron N = Stainless P = Plastic S = Brass |
Coating
1 = Electro Galvanized 2 = Hot Galvanized 3 = Electro Copper 4 = Electro Tin 5 = Electro Chromium-Nickel 6 = Black Isolation 7 = Yellow-Green Insulation |
Bolt - Nut DC = Galvanized NC = Stainless SC = Brass |
